dw0522 LED Recessed Spotlight high professional SUMBAO

dw0522 LED Recessed Spotlight high professional SUMBAO

Brand Name
SUMBAO Lighting
Delivery Time
Normally 10 Days (depends on order quantity)
OEM/ODM
Both acceptable
Warranty
3 Years(Lumen maintenance>90%)
Brand: SUMBAO Lighting
Type: DW028-3 head recessed spotlight
Size: 425X135X180mm
Color: Dumb white
Color temperature: 2700K/3000K/3500K/4000K/5000K
Material: Specification grade AL
Light source: Imported COB chip
Power supply: AC220~240V 50/60Hz
Wattage: 3x10W/3x18W
Beam: 12°/15°/20°/33°
Installation: Embedded
Hole: 410X120mm
Applications: Shopping center, Clothing store, Supermarket, Exhibition room, Furniture store etc.
Company Advantages
1. All LED Recessed Spotlight materials of SUMBAO are wisely made by 4 inch recessed lighting. Strict Quality Under the Control of QC Team & Advanced Testing Machine
2. The team spirit is also there which motivate us to work with full dedication and achieve the target goals. a strict QC team and advanced testing system to ensure supreme quality before shipment
3. LED Spotlight is one of the leading manufacturers and suppliers of steel structure. 7 Professional Certification in LED Manufacturing
4. Training programs at Dongguang SUMBAO Lighting Technology Co. Ltd facilities are designed to create a skilled and responsible workforce, able to meet and exceed the customer requirements and expectations, across all activities. Multiple packaging to ensure safe delivery
Specification

Model number: DW028-3 LED Recessed light

TypeLEDWattage      (W)BeamTemperatureCRIVoltage      (Vac)Life      (H)Size      (mm)Cutout      (mm)
DW028-3LUMINUS COB10/1812°/15°/20°/33°2700K/3000K/3500K/4000K/5000K>80220-24030,000425X135X180410X120
SHARP COB10/1812°/15°/20°/33°2700K/3000K/4000K/5000K>80220-24030,000425X135X180410X120


SUMBAO Multi-Head LED luminaires are ideal for retail accent lighting,  provide attractive, versatile, and ultra-efficient accent lighting in retail applications.



Quality, flexibility, and good looks have endeared SUMBAO Multi-Head LED luminaires to retailers, designers, and installers alike. With the introduction of the new series, SUMBAO Multi-Head LEDs now offer more performance and efficiency than ever before. The 18W version of these fixtures produces up to 3074 delivered lumens per head, with efficacies of up to 89lm/W. Rated service life is a remarkable 50,000 hours at 90-percent lumen maintenance.



Product sketch





Product Features:



Imported COB LED technology for maximum brightness,high luminous efficacy and high CRI

ANSI Compliant warm/neutral LED bins for a finer color consistency

Delicate appearance, unique modeling, with deep modernbreath.

Specification grade die cast aluminium with sophisticated technology and durable quality, superior heat disspition.

Powder coated surface, gentle and smooth, durable and fashionable.

Universal compatible,replacable lens,with 360° horizontal rotation and 40° vertical adjustment,easily meet the variable scenes.

Environmental-friendly: No RF interference and no flickering, No hazard of mercury or led

Long life span and high in reliability, good at heating dissipation and stability.

Smooth and continuous 2.4G dimming and LiteTrace dimming

7.2mm thick trims mount to ceiling for a thin profile look

Suitable for 1mm~25mm thick ceilings

Easy installation  simple and fast to adjust



Application case






DW028-3-18W-3000K-12°



0 degree
D(M)LUXWL
1155710.230.23
2.524910.560.56
317300.680.68
49730.900.90
64321.351.35

Company Features
1. Call Now! SUMBAO's LED Recessed Spotlight, 4 inch recessed lighting, low profile recessed lighting Are Made Of High Quality Materials And With Innovative Design. We Promise To Meet Customers' Requirement.
2. These products are also provided in varied options in order to meet the clients’ specific requirements.
